Máy chủ FUJITSU PY TX2540 M4, Silver 4114, Ram 16GB, 8x2.5"

0₫

Mô tả

Máy chủ FUJITSU PY TX2540 M4, Silver 4114, Ram 16GB, 8x2.5"

- Processors : 1x Intel Xeon Silver 4114 (2.2GHz, 10C/20T, 85W)
- Memory : 16GB (1x16GB) 1Rx4 DDR4-2666 R ECC
- Hard Drives : Option
- Drive Bays : Basic 2.5' kit (8x)
- Raid Controller : PRAID EP420i
- Network Controller : PLAN EM 4x 1Gb T OCP interface
- Optical Drive : Option
- Powe Supply : 1x 800W
- Form Factor : 2U


Specifications

Chipset Intel®:
 C624

Mainboard type:                D3383

Product Type:     Dual Socket Rack Server

Processor:            Intel® Xeon® Processor Scalable Family
                                   1-2

Memory:              8 GB - 3.072 GB, DIMM (DDR4)

Memory protection:        Advanced ECC, Memory Scrubbing, SDDC, Rank sparing memory support, Memory Mirroring support

Drives (optional):
LTO5HH Ultrium, 140 MB/s, 1,500 GB, SAS 6Gb/s
DVD supermulti, ultraslim, SATA I
RDX Drive, 100 MB/s, 320 GB, 500 GB, 1 TB, 2 TB, USB 3.0
LTO6HH Ultrium, 160 MB/s, 2,500 GB, SAS 6Gb/s
LTO7HH Ultrium, 300 MB/s, 2,500 GB, SAS 6Gb/s

PCI-Express 3.0 x8:            3 x Low profile (2nd processor required for slot 4)

PCI-Express 3.0 x1:6          3 x Low profile (2nd processor required for slot 5 and 6)

Slot Notes:          One PCIe Gen3 x8 slot may be occupied with a Modular RAID controller if configured.
Important: 3 PCIe slots are supported with the first processor. 6 PCIe slots are supported with two processors.
PCIe riser card options can expand number of slots by two (max. 8 in total) and support max. 4 full height slots.
Possible slot length described in relevant system configurator.

Accessible drive bays:      1 x 5.25/0.4-inch for CD-RW/DVD

Optional accessible drives:
ODD 5.25" possible
ODD 5.25" NOT possible
All possible options described in relevant system configurator.

Storage drive bays :
3.5-inch or 2.5-inch hot-plug SAS/SATA
4 x 3.5-inch hot-plug SAS/SATA
12 x 3.5-inch hot-plug SAS/SATA
16 x 2.5-inch hot-plug SAS/SATA
8 x 2.5-inch hot-plug SAS/SATA
24 x 2.5-inch hot-plug SAS/SATA

I/O controller onboard:
Intel® C624, 1 x SATA channel for ODD
All hardware storage controller options are described under Components, For dedicated base units front AND rear storage drives may be connected to a single controller. Please see SystemArchitect for configuration options and restrictions.
2 x 1Gbit/s onboard, Optional DynamicLoM OCP adaptors:, 4 x 1 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s SFP+, 4 x 10 Gbit/s SFP+
Integrated Remote Management Controller (iRMC S5, 512 MB attached memory incl. graphics controller), IPMI 2.0 compatible
GFX/GPU support for dedicated base units. Please see relevant SystemArchitect for details and restrictions.

Trusted Platform Module:  Infineon / TPM 1.2 or TPM 2.0 module; TCG compliant (option)

Power supply configuration:        1 x hot-plug power supply or 2x hot-plug power supply for redundancy

Active power (max. configuration):            715 W

Weight: up to 25 kg

Rack (W x D x H):              482.4 mm (Bezel) / 445 mm (Body) x 770 x 86.6 mm

Mounting Depth Rack:     740 mm

Server Management:      Server Management

Option:  ServerView Suite (Maintain), ServerView eLCM, iRMC Advanced Pack incl. Advanced Video Redirection (AVR), video capturing and Virtual Media, ServerView Suite (Dynamize), ServerView Virtual IO Manager (SVIOM), Resource Orchestrator- virtual edition, Resource Orchestrator- Cloud edition
